EziLab offers the Vertical Gel Electrophoresis EZL-VGE101, a mini gel box that runs one to four 83 by 73 mm polyacrylamide gels at once. Short glass plates measure 100 by 73 mm and spacer plates 100 by 83 mm, with 0.75, 1.0, and 1.5 mm gel thickness options and matching 10 and 15 well combs. A sliding wedge fastener, press-lock clamp, and flat glass support seal the plates against leaks. Vertical casting suits SDS-PAGE, native PAGE, and small nucleic acid fragments, so this SDS-PAGE apparatus covers protein separation and purity checks. Thinner 0.75 mm gels sharpen bands for closely sized proteins, while 1.5 mm gels take heavier loads, and 15 well combs fit more samples. Running four gels in parallel lets analysts pair a stained gel with a transfer gel for western blot equipment downstream. University molecular biology and biochemistry labs run it for coursework and research gels, while biotech and diagnostics companies check recombinant protein expression and purification fractions. Pharmaceutical QC teams confirm biologic purity, and clinical research labs screen patient-derived protein samples. As shared electrophoresis equipment, its four-gel capacity suits busy core facilities. Pair this tank with a power supply rated for four gels at once, which the Electrophoresis Apparatus category lists alongside the Vertical Gel Electrophoresis range.



Quantity:
$2401
Gel Quantity 1 to 4 gels
Gel Thickness 1.0 mm, 0.75 mm,1.5 mm
Glass Plates Short glass plate: 100×73 mm; Spacer glass plate: 100×83 mm
Gel Size 83×73 mm
Combs 1.0 mm: 10 and 15 wells (standard accessories)0.75 mm: 10 and 15 wells1.5 mm: 10 and 15 wells
Dimensions (L × W × H) 180 × 130 × 160 mm
Weight 19.5 Kg
Feature AreaDescription
Gel QuantityRuns 1 to 4 gels at a time.
Gel ThicknessGel thickness options of 0.75 mm, 1.0 mm and 1.5 mm.
Gel Size and Plates83 × 73 mm gel, with a 100 × 73 mm short glass plate and a 100 × 83 mm spacer glass plate.
Combs10-well and 15-well combs for each gel thickness.
FasteningSliding wedge fastener and press-lock mechanism with stable flat glass support.
  • Applied by molecular biology and biochemistry labs for SDS-PAGE and native PAGE on 83 × 73 mm gels.
  • Employed by biotech labs checking recombinant protein expression and purification fractions.
  • Suited to diagnostics labs running 10- or 15-well combs across 3 gel thicknesses.
  • Supports core facilities running 4 gels in parallel.
  • Handles thin 0.75 mm to thick 1.5 mm gels for different loading needs.
  • Fits benches that fasten glass plates with the sliding wedge and press-lock mechanism.
