EziLab offers the Digital Viscometer EZL-DV414, a compact viscosity tester that reads from 1 to 100,000 mPa·s within 5% at rotor speeds from 6 to 60 rpm. A 16-bit microprocessor drives the measurement, while a bright back-lit digital display and a direct-access keypad keep settings handy. At 95 by 130 by 155 mm and 2 kg, it fits on crowded benches and works in rooms from 5°C to 35°C. Multiple rotor speeds let one viscometer cover thin liquids and moderately thick formulations up to 100,000 mPa·s. Labs use it for viscosity measurement on solvent-based adhesives, emulsions, biochemicals, paints, coatings, cosmetics, printing inks, paper, pulp, and food. Readings at fixed speeds make batch-to-batch comparison simple, so formulation drift shows up before products leave the lab. Its wide 6 to 60 rpm span suits both routine QC and research testing. Paint, ink, and coating manufacturers check viscosity right before filling, while adhesive and emulsion producers confirm consistency on the line. Cosmetic and pharmaceutical labs test lotions and liquid formulations, and food plants monitor ingredient batches daily. As a lab viscometer or benchtop viscosity meter, its small footprint suits crowded QC benches. See the Digital Viscometers and Digital Viscometer pages for full specifications.
| Measurement Range | 1-1×10(5) mPas |
|---|---|
| Speed | 6 to 60 rpm/min |
| Precision | ±5% |
| Working Condition | 5°C to 35°C |
| Relative Humidity | Less than 80°C |
| Outline Dimension (W×D×H) | 95mm×130mm×155mm |
| Out Packaging Dimensions (W×D×H) | 475mm×220mm×375mm |
| Net Weight | 2 Kg |
Select all functions from user friendly keypad
Simplifies user interface for more direct access to features
Employs 16 bit high performance chip micro processing technology
Contains bright easy to read digital display
Multi optional rotating speeds satisfy different measurement range
Compact design with no additional space requirement
Operator convenient back-lit display
It is widely used in measurement of viscosity in industrial and research applications, solvent based adhesives, emulsions, bio-chemicals, paints, coatings, cosmetics, printing inks, paper, pulp, food, etc.
