EziLab offers the UV-Visible Spectrophotometer EZL-US113, a single beam touchscreen UV-Vis spectrophotometer covering 200 to 1000 nm with a 2 nm bandwidth for routine pharmaceutical and QC absorbance work. Choose it when methods stay inside the core UV and visible range and skip the 190 nm or 1100 nm extremes, and over the LCD-based US114 when lower stray light and on-screen data storage matter. Stray light stays at ≤0.1% T at 220 and 360 nm, a third of the US114 figure, which keeps absorbance readings linear at higher concentrations. Wavelength accuracy holds at ±2 nm with ≤1 nm repeatability through a 1200 lines/mm grating, and photometric accuracy reaches ±0.5% T with ≤0.2% T repeatability. Readings cover 0 to 100% T, 0 to 1.999 Abs, and 0 to 1999 concentration on a silicon photocell detector. The touchscreen panel simplifies method setup, built-in data storage keeps results on the instrument, and sensor protection technology guards the detector. Pharmaceutical labs run routine compound assays, biochemical and clinical labs measure proteins and other analytes, QC teams check incoming raw materials, and universities and institutes use it for teaching and research. On-screen storage can replace a bench PC for routine absorbance checks, so count how many methods you run before comparing the Spectrophotometer category and Single Beam UV-Visible Spectrophotometer range.
| Wavelength Range | 200 to 1000 nm |
|---|---|
| Optical System | Single Beam |
| Bandwidth Options | 2 nm |
| Wavelength Accuracy | ± 2nm |
| Wavelength Repeatability | Less than or equal to 1nm |
| Photometric Accuracy | ± 0.5 %T |
| Photometric Repeatability | Less than or equal to 0.2 % T |
| Photometric Range | 0.0–100%(Transmittance)0-1.999 (Absorbance) 0-1999 (Concentration) |
| Stray Light | Less than or equal to 0.1 % T at 220 nm & 360 nm |
| Grating | 1200 lines /mm |
| Detector | Silicon Photocell |
| Power Requirements | AC 220 V ± 22V 50Hz ± 1 Hz 120W |
| Packaging Size | 580 × 460 × 345nm |
| Gross weight | 16.5Kg |
User Manual | 1 piece |
1 cm Glass Cuvette | 4 pieces |
1 cm Quartz Cuvette | 2 pieces |
Power Cord | 1 piece |
Fuse | 2 pieces |
1. | Thermal Printer |
2. | Cuvette Holder 50nm |
| • | Running routine absorbance checks in pharmaceutical quality control between 200 and 1000 nm. |
| • | Checking sample concentration in biochemical laboratories. |
| • | Performing assays in clinical laboratories within the core UV and visible range. |
| • | Measuring absorbance, transmittance and concentration for general research. |
| • | Storing routine absorbance results on the built-in memory in place of a bench PC. |
The UV-Visible Spectrophotometer EZL-US113 Single beam is designed for efficiency and reliability, making it well-suited for daily laboratory operations. Its easy-to-use interface and stable performance allow technicians to perform quick analyses with minimal training. The instrument minimizes user errors with simple workflows, which is particularly useful in teaching labs and quality control environments. The EZL-US113 is therefore a dependable choice for labs handling frequent sample testing.
Our UV-Visible Spectrophotometer EZL-US113 Single beam delivers consistent results by using precise optics and stable measurement performance across repeated runs. This reliability ensures that even small changes in sample absorbance can be detected clearly. Consistency is especially important in pharmaceutical and environmental testing where reproducibility of results is critical. The instrument gives professionals confidence in the accuracy of their data, reducing the need for repeat testing.
Ezilab’s UV-Visible Spectrophotometer EZL-US113 Single beam is versatile and supports analysis of a wide range of samples, including biological, chemical, and environmental solutions. Its broad wavelength range allows for testing of both organic and inorganic compounds effectively. This flexibility makes it a valuable instrument in diverse fields such as academic research, clinical diagnostics, and industrial quality control. Laboratories benefit from its ability to adapt to multiple testing requirements.
Our UV-Visible Spectrophotometer EZL-US113 Single beam incorporates safe operating features to protect both the instrument and users. Its enclosed optical system ensures that light exposure remains within safe limits during testing. Automatic system safeguards help prevent errors during setup or measurement. These measures make it safe to operate even in high-throughput laboratory settings.
Our UV-Visible Spectrophotometer EZL-US113 Single beam is widely used for applications such as concentration measurement, purity checks, and kinetics studies. In academic settings, it supports student learning through hands-on experiments, while in industrial labs, it assists with quality control and product validation. Clinical and environmental labs also rely on it for accurate sample analysis. Its broad applicability makes it a versatile tool across scientific disciplines.
