EziLab offers the Infrared Thermometer EZL-IT101, an industrial laser thermometer that reads from -50°C to 850°C (-58°F to 1562°F) with a 12:1 distance-to-spot ratio and 0.5 second response. Readings stay within 2% above 100°C and within 2°C below it, with 1% repeatability and 0.1° resolution across a 5 to 14 µm band. Adjustable emissivity from 0.1 to 1.0, a color LCD, smart temperature alerts, and a 202 g body keep it practical. A K-type thermocouple socket adds contact measurement, so one IR thermometer checks both surface and internal temperatures, and adaptive mode switching moves between the two. Staff aim at kiln walls, furnace surfaces, motors, and electrical panels from a safe distance, then adjust emissivity for metal, glass, or painted finishes. As a non contact thermometer, it also verifies pharmaceutical storage and cold chain conditions without opening packages. Ceramic and glass plants monitor kiln and furnace temperatures, metalworking shops check heat treatment, and maintenance crews run this temperature gun on electrical inspections to spot overheating connections. Pharmaceutical warehouses, cold chain logistics teams, laboratories, and medical facilities log storage checks. It suits high temperature infrared thermometer work below foundry extremes. See the Infrared Thermometers and Infrared Thermometer pages for full specifications.
| Temperature Range | -50 to 850℃ (-58 to 1562°F) |
|---|---|
| Measurement Accuracy | Greater than or equal to 100°C: ±2% ; Less than or equal to 100°C: ±2°C |
| Measuring Distance Ratio | 12:1 |
| Emissivity | 0.1 to 1.0 |
| Response Time | 0.5 seconds |
| Wavelength | 5 to 14 μm |
| Repeatability | 1% or 1°C |
| Resolution | 0.1°C or 0.1 °F |
| Storage Temperature | -10 to 60°C (-14 to 140 °F) |
| Operating Temperature | 0 to 40°C (32 to 104 °F) |
| Operating Humidity | 10-90% |
| Display | Colour LCD Display |
| Low Battery Indication | Less than 2.4 V |
| Product Dimension | 108 × 49 × 177 mm |
| Weight | 0.202 Kg |
| Feature Area | Description |
| Temperature Range | Covers -50 to 850 °C for non-contact surface readings. |
| Optics | 12:1 distance-to-spot ratio with a 5 to 14 µm spectral range. |
| Emissivity | Adjustable from 0.1 to 1.0 to suit different surface types. |
| Response and Resolution | 0.5 s response time with 0.1 °C and 0.1 °F readout steps. |
| Contact Input and Display | K-type thermocouple socket and a colour LCD in a 108 × 49 × 177 mm body. |
Name | Quantity |
K-Type Thermocouple Socket | 1 Piece |
Ezilab’s Infrared Thermometer EZL-IT101 is equipped with a 12:1 distance-to-spot (D:S) ratio, ensuring precise measurements from a safe working distance. This means that at 12 inches away, the device accurately measures a 1-inch diameter target area, allowing you to capture smaller surface readings without moving closer. Such precision is particularly valuable when working with hot equipment or moving components. The D:S ratio supports both safety and accuracy, making it well-suited for industrial and maintenance tasks. It minimizes the risk of contamination and guarantees that measurements are taken exactly where intended. The integrated laser targeting system further enhances accuracy and user confidence.
Our Infrared Thermometer EZL-IT101 is designed to safeguard users from direct exposure to hazardous or extreme temperature surfaces. By enabling non-contact measurement, it eliminates the need to touch hot, cold, or potentially contaminated materials. Its built-in laser pointer ensures precise aiming, reducing the chance of mistakes and the need for repeated checks. The device also features a temperature difference alarm that signals sudden fluctuations, which may indicate system malfunctions such as overheating or cooling failures. Built with a durable body to withstand tough conditions, the thermometer supports safer work practices. Its ergonomic grip provides comfort even during long inspection routines.
Ezilab’s Infrared Thermometer EZL-IT101 is engineered to accurately measure temperatures across a wide variety of surfaces, including metals, liquids, glass, plastics, and coated finishes. With an adjustable emissivity range from 0.10 to 1.00, it ensures reliable readings on different materials. This adaptability is especially useful in environments like laboratories, warehouses, and automotive facilities, where surfaces can vary significantly. Whether moving between reflective metal pipes and matte painted equipment, the thermometer maintains consistent accuracy. Its broad measuring range makes it suitable for both routine checks and specialized applications.
Our Infrared Thermometer EZL-IT101 is designed with an intuitive control panel and a bright, backlit LCD display for effortless operation. Clearly labeled buttons allow quick switching between Celsius and Fahrenheit, adjusting emissivity, and activating the laser targeting system without navigating complex menus. User-friendly icons and indicators make settings easy to interpret at a glance. Battery status and overload alerts keep informed, ensuring uninterrupted use during critical tasks. Convenient data storage and recall functions help you review past measurements instantly.
Ezilab’s Infrared Thermometer EZL-IT101 comes with built-in data storage and recall features, allowing you to save and access previous temperature readings with ease. This capability is especially valuable for monitoring temperature patterns over time in areas such as preventive maintenance, research, and quality control. Stored data can be retrieved instantly on the display, eliminating the need for manual record-keeping. By maintaining accurate logs, the device supports compliance with safety standards and simplifies reporting for inspections and audits. It also provides a reliable reference when analyzing or troubleshooting issues.
