EziLab offers the Multi Plate Vortex Mixer EZL-MPV104, a digital lab vortex mixer that drives interchangeable plates in a 4.5 mm circular orbit from 100 to 3000 rpm in run mode and from 0 to 3000 rpm in touch mode. A brushless motor answers to PWM speed control, an LCD shows speed and time, and the timer spans 1 minute to 8 hours. Plates hold four 50 mL tubes, nine 15 mL tubes, twelve 5 to 10 mL tubes, or twenty-four 2 mL tubes, the IP21 shell suits 5 °C to 40 °C and 80 % humidity, and draw is 20 W. Choose it over the knob-driven siblings when speed and time must be set digitally. Molecular biology, pharmaceutical and diagnostic labs process many containers per run, so handling drops and each rack gets the same swirling motion, while biotechnology groups keep cultures suspended on a crowded bench. Typical uses include sample preparation, reagent mixing, DNA and RNA extraction, enzyme assays, and blood collection tube mixing. Ask whether plates swap without tools and what spare plates cost; wider mixers sit under Lab Equipment and Lab Mixer.



Quantity:
$1647
Operating Mode Touch/Run
Control Mode PWM speed adjustment
Display LCD
Motor Type Brushless motor
Speed Range Touch: 0 to 3000 RPM
Run: 100 to 3000RPM
Timing/Time 1min-8h
Shell protection level IP21
Amplitude 4.5 mm circular oscillation
Max Capacity 50 ml × 4
15ml × 9
5 to 10ml × 12
2ml × 24
Operating Temperature 5 to 40°C
Operating Humidity 80% RH
Power Consumption 20 W
Feature AreaDescription
Mixing MotionCircular orbital motion that gives each rack the same swirling action.
Motor & SpeedBrushless motor with digital speed control in place of a manual knob.
Display & TimerLCD showing speed and time, with a digital timer that has a wide time range.
PlatesInterchangeable plates for centrifuge tubes, test tubes, blood collection tubes and microplates.
Modes & HousingTouch mode and run mode in a protective housing with quiet operation.
  • Centrifuge tube/test tube

  • Flask or multiple tubes

  • Blood collection tubes (D:12mm × 21)

  • 50ml Centrifuge tube 4

  • 5ml/15ml Centrifuge tube 5

  • 0.2ml Centrifuge tube 96
  • 96 well plate
  • 0.5ml Centrifuge tube 20
  • 1.5ml/2.0ml Centrifuge tube 30
  • Cell culture plate
  • Supports sample preparation and reagent mixing in molecular biology labs.
  • Handles DNA and RNA extraction steps in pharmaceutical labs.
  • Suited to enzyme assays in biotechnology groups.
  • Applied to cell culture plate mixing.
  • Employed for blood collection tube mixing across several containers at once.
