EziLab supplies the -86C Ultra-Low Temperature Freezer EZL-UF158 for pharmaceutical and clinical laboratories that need capacity between the 608L and 938L units in this catalog. At 808L capacity with a -60 to -86°C operating range, this lab freezer gives facilities substantial storage volume approaching the largest available cabinet while using the same wider temperature range as the mid-to-large tier freezers rather than the narrower -65 to -86°C span found on the smaller compact units. That 808L capacity suits pharmaceutical and clinical facilities with a growing inventory that has outpaced the 608L unit but doesn't yet require the maximum 938L capacity, giving a practical step between those two tiers as sample volume increases over time. The -60 to -86°C range covers both moderate deep-freeze and true ultra-low storage needs on the same instrument, suited to facilities storing a mix of material types rather than exclusively the deepest-cold-sensitive samples the narrower-range compact units focus on. Pharmaceutical and clinical facilities scaling up storage capacity beyond the 608L tier, without yet needing the absolute maximum available volume, get an appropriately sized option here. See the Lab Freezer and -86C Ultra-Low Temperature Freezer ranges for large-capacity flexible-range deep-cold storage needs across USA pharmaceutical and clinical laboratory settings.
| Capacity | 808 L |
|---|---|
| Temperature Range | -60° to -86°C |
| Maximum Ambient Temperature | 28°C |
| Cooling Time | 300 minutes (no load) |
| Hold Over Time | 180 minutes |
| Noise | 55 dB |
| Defrost | Manual |
| Insulation | 120 mm |
| Sensor | PT 100 |
| Compressors | 2 |
| No of Shelves | 3 |
| Inner Material | 306 Stainless steel |
| Outer Material | Galvanized sheet spraying |
| Power | 1290 W |
| Energy Consumption | 14.7 KW/Hr |
| Interior Dimension (W×D×H) | 850×735×1335 mm |
| Exterior Dimension (W×D×H) | 1090×1010×2025 mm |
| Net Weight | 270 Kg |
| Gross Weight | 310 Kg |
Digital display for ease of operation
Adjustable shelves for sample holding
This freezer is used for storing all sorts of medical equipment
Independent inner door minimizing loss of cold temperature
Easy to use built-in handle design
Condenser requires no liquid cooling agent
CFC free refrigeration system
Multi-level security
Compressors are protected with constant flow of refrigerant
Rugged construction with cold rolled steel cabinets
Stainless steel interiors
Direct cooling for optimized temperature stability and uniformity
Used for storing and preservation of reagents, medicines, vaccines, disinfectant, liquid chemical Sterilants and also meets the requirements in the field of R&D, biomedical, electronic and chemical industries.
