EziLab’s Horizontal Pressure Steam Sterilizer EZL-HS81 runs a 150L stainless steel chamber from 40C to 134C at 0.22 MPa working pressure, with sterilization and drying cycles adjustable from 0 to 99 minutes each and heat averaging within 2C across the load. A pressure-lock door, steam exhaust safety valve, and user-friendly interface keep daily cycles straightforward, while a programmable drying phase and automatic sterilization cycle reduce manual steps between loads. Rated at 9KW on 380V, the unit suits high-volume, busy facilities. As a horizontal autoclave built for high-throughput loads, this unit supports culture media preparation in laboratories alongside routine instrument sterilization in hospitals. Clinical diagnostics labs rely on it to sterilize glassware and media ahead of daily testing, while research facilities use the wide temperature range for both sterilization and controlled heating in one chamber. Food industry processors apply the same industrial autoclave to sterilize containers and ingredients under strict hygiene programs, and hospital central sterile departments use it for bulk surgical instrument turnover between procedures. Multi-department facilities standardize on a steam sterilizer of this size to cut wait times across busy shifts. Shift patterns and load size set the chamber volume you need, so look at the Autoclave page first and the Horizontal Pressure Steam Sterilizer page next.
| Sterilization Chamber Volume | 150L |
|---|---|
| Working Pressure | 0.22MPa |
| Working Temperature | 134˚C |
| Adjustment of Temperature | 40 ˚C to 134˚C |
| Time of Sterilization | 0 to 99 minutes |
| Time of Drying | 0 to 99 minutes |
| Heat Average | Less than equal to ± 2℃ |
| Power | 9KW/380V/50Hz |
| Dimensions(W×D× H) | 1400×650×1600mm |
| Transport Dimensions(W×D×H) | 1560×820×1820mm |
| Gross Weight | 430Kg |
| Net Weight | 340Kg |
| Feature Area | Description |
| Chamber | 150 L stainless steel sterilization chamber. |
| Temperature and Pressure | 134 °C working temperature, adjustable from 40 °C to 134 °C, at 0.22 MPa working pressure. |
| Cycle Times | Sterilization time and drying time each set from 0 to 99 minutes, with an automatic sterilization cycle. |
| Power | 9 kW power at 380 V and 50 Hz. |
| Safety | Pressure-lock door mechanism and a steam exhaust safety valve. |
The Horizontal Pressure Steam Sterilizer EZL-HS81 is built to ensure thorough and consistent sterilization while maintaining the integrity of sensitive instruments. The system’s pressure and temperature are carefully regulated to eliminate contaminants without damaging delicate items. Safety interlocks and automatic pressure release features prevent accidental exposure during the cycle. The intuitive control panel also reduces handling errors, especially during high-volume workflows. This makes it a reliable sterilization solution for labs managing varied equipment types.
Ezilab’s Horizontal Pressure Steam Sterilizer EZL-HS81 is designed to accommodate a wide range of laboratory materials, including glassware, surgical tools, media, and textiles. The chamber size and horizontal loading design make it especially suitable for bulk loads and large instruments. Whether you're processing reusable tools or preparing media for microbiology, the system ensures consistent sterilization. Its adaptability is beneficial for both clinical and industrial laboratory environments. Proper loading practices further ensure uniform exposure for optimal results.
The Horizontal Pressure Steam Sterilizer EZL-HS81 is equipped with a clear control interface that simplifies the setup and monitoring of sterilization cycles. Pre-programmed settings reduce manual inputs, making operation quick and efficient even for less experienced users. Audible and visual alerts keep users informed of cycle status and completion. Maintenance prompts help ensure timely upkeep without guesswork. Altogether, these features enhance ease of use while supporting consistent outcomes.
Our Horizontal Pressure Steam Sterilizer EZL-HS81 is engineered for long-term durability and consistent performance, even under demanding usage. Its robust construction and corrosion-resistant chamber ensure it withstands repeated sterilization cycles. Preventive maintenance is supported by system alerts and access points for easy inspection. Regular cleaning and periodic checks on gaskets and valves help extend service life. With proper care, labs can rely on it for daily sterilization needs without interruption.
The Horizontal Pressure Steam Sterilizer EZL-HS81 prioritizes user safety through features like automatic door locking during pressurization and controlled steam exhaust systems. Pressure and temperature sensors monitor conditions in real time to prevent unsafe operation. The outer casing remains insulated, minimizing heat transfer to users. Emergency stop functions are also included for added security. These safeguards help laboratories operate confidently with minimal risk.
Ezilab’s Horizontal Pressure Steam Sterilizer EZL-HS81 offers customizable sterilization durations and drying times, making it suitable for various material types and sterilization protocols. Whether you're handling wrapped instruments or liquid media, you can tailor cycles to ensure complete sterilization without compromising material integrity. Its programmable logic controller ensures accurate control over each phase of the process. This flexibility makes it well-suited for research, diagnostic, and pharmaceutical environments. It adapts well to shifting lab needs.
