EziLab offers the Table Top Steam Sterilizer EZL-ST64, a 50 L benchtop autoclave that doubles the capacity of standard 20 to 24 L units while staying on the countertop. Choose it when daily instrument batches outgrow a small autoclave but floor space or budget rules out a floor-standing model, and choose a pulse vacuum unit instead when loads are wrapped, porous, or hollow. The ɸ340 × 550 mm stainless steel chamber sterilizes from 105 to 134°C at 0.22 MPa with ≤ ±1°C heat uniformity, and the rapid cycle completes sterilization in 4 to 6 minutes at 134°C. Four 500 × 250 × 30 mm sterilizing plates organize instruments, glassware, and media in layers. Fully automatic microcomputer control handles water addition, sterilization, and dry steam discharge, with automatic purging keeping the chamber clean. A rapid action door with a safety lock and leak-proof gasket seals tightly on each cycle. Hospitals, clinics, and dental practices sterilize solid instruments between patient appointments, pharmacy QC, QA, and R&D labs prepare sterile tools and media, biotechnology labs process glassware, and chemical, environmental, and mineral water plant laboratories sterilize sampling equipment. Clearance for door swing and steam discharge is easy to overlook on a countertop, so measure the space before comparing the Autoclave category and Table Top Sterilizer range.
| Chamber Volume | 50 L |
|---|---|
| Sterilizing Temperature Range | 105°C - 134°C |
| Working Temperature | 134°C |
| Working Pressure | 0.22 Mpa |
| Timer Range | 0-99 min |
| Rapid Sterilization | 4 – 6 minutes |
| Sterilizing Plates | 4 |
| Heat Average | ≤ ±1°C |
| Sterilizing Chamber Dimension | ɸ340×550 mm |
| Sterilizing Plate Dimension | 500×250×30 mm |
| Dimension (L×W×H) | 580×480×384 mm |
| Exterior Package Dimension (L×W×H) | 880×730×700 mm |
| Gross Weight | 105 Kg |
| Net Weight | 86 kg |
High grade stainless steel chamber
Rapid action door closure mechanism
Standard operation via a digital display
High-efficiency and easy to use
Exhausts the cool air automatically
Water adding, sterilizing, dry steam discharging are controlled automatically
Steam-water inner circulation system
Electrical draining of water reservoir
Automatic purging of steam and exhaust with water
Fully automatic micro-computer controlled operation
Leak-proof sealing with gasket design
Offers rapid sterilization of 4 – 6 minutes within 105°C to 134°C temperature range
Provides clean and dry environment for sterilization
Safety door lock system
| • | Sterilizing solid instruments between patients in hospitals, clinics and dental practices. |
| • | Sterilizing tools and media for pharmacy QC and QA work. |
| • | Preparing sterile tools and culture media in R&D laboratories. |
| • | Processing glassware in biotechnology laboratories with the 50 L chamber. |
| • | Sterilizing sampling equipment in mineral water plants and water and air pollution laboratories. |
