EziLab hematology analyzer EZL-HA101 delivers 60 tests/hour with 21 parameters and impedance-based cell counting using a cyanide-free HGB method for automated blood analysis in clinical and diagnostic labs. The hematology analyzer machine processes venous, capillary, and pre-diluted samples with WBC, RBC, and PLT histograms across 3 dedicated aperture chambers — 100µm for WBC and 70µm for RBC/PLT. Storage capacity of 100,000 results with histogram data supports high-volume routine diagnostics, while manual and auto calibration maintain measurement consistency. An 8-inch touchscreen with RS232, USB, and VGA output ports plus built-in thermal printer and LIS connectivity enable seamless data handling for clinical diagnostics, blood banks, and research institutes. Explore EziLab's hematology analyzer range and analyzers for related products.
| Sample Volume | Normal: 10µl, 20µl (pre-diluted blood) |
|---|---|
| Throughput | 60 tests/hour |
| Storage | 1,00,000 results with histogram |
| Histograms | 3 histograms (including WBC, RBC, PLT) |
| Aperture Diameter | WBC Chamber: 100µm; RBC/PLT Chamber: 70µm |
| Measuring Principle | Impedance for cell counting Cyanide free method for HGB |
| Parameters | WBC, NEU#, LYM#, MID#, NEU%, LYM%, MID%, RBC, HGB, HCT, MCV, MCH, MCHC, RDW-SD, RDW-CV, PLT, MPV, PDW, PCT, P-LCR |
| Calibration | Manual and auto calibration |
| Counting Modes | Venous, Capillary, Pre-diluted |
| Printer | Built-in thermal printer, USB to external printer |
| Data Input | 8 inch touch screen, keyboard, mouse |
| Output | RS232 port, USB port, VGA port, LIS system available |
| Parameter (CV) | 21 parameters (including WBC, Mid%, Lym%, Gran%, Mid%, Lym%, Gran%, RBC, HGB, HCT, MCV, MCH, MCHC, RDW-SD, RDW-CV, PLT, MPV, PDW, PCT, LCR, P-LCC) |
| Background Parameter | WBC ≤ 0.3× 10⁹/L, RBC ≤ 0.03 × 10¹²/L, HGB ≤ 1g/L, HCT ≤ 5.0%, PLT≤ 10×10⁹ /L |
| Power Supply | AC 220±10%, 50/60Hz, 110±10%, 60Hz |
| Package Size (W×D×H) | 580×470×590 mm |
| Reagent Package Size (W×D×H) | 450×410×310 mm |
| Gross Weight | 27 kg |
Accurate results with regular and micro-sampling collection tubes with only 20µl blood required and results in less than 1minute
Large touchscreen with specially designed user interface for non-experienced operators
Easy, safe and biohazard free on-board integrated reagent pack
Fast and reliable, user friendly, portable and cost effective
8 inch user friendly touch screen operator panel
Support LIS and external printer
3 counting modes
This instrument is suitable for many testing scenarios such as Satellite laboratories, Clinics and Routine laboratories.
