EziLab supplies the Table Top Steam Sterilizer EZL-ST63 for clinical laboratories that need capacity between the 24L and 50L table top units in this catalog, with a 4-plate tray configuration rather than the 3-plate setup found on the smaller model. At 35L capacity and 134°C, this lab autoclave keeps the same rapid 4-6 minute sterilization cycle that makes table top units practical for busy clinics, while the extra plate position gives slightly more per-cycle capacity than the 24L unit without reaching the larger 50L model's full batch size. That 35L intermediate tier and 4-plate configuration suit clinics whose daily instrument volume has outgrown the 24L unit's 3-plate capacity but doesn't yet require the 50L model's substantially larger throughput, giving a finer-grained capacity step between those two more widely spaced options. The rapid cycle time holds steady across this intermediate size, so clinics gain plate capacity without a proportionally longer wait between sterilization runs. Clinical practices with growing but still moderate daily sterilization needs get an appropriately sized option between the standard and high-capacity tiers here. See the Lab Autoclave and Table Top Steam Sterilizer ranges for intermediate-capacity clinical sterilization needs across USA clinical laboratory settings.
| Chamber Volume | 35 L |
|---|---|
| Sterilizing Temperature Range | 105°C - 134°C |
| Working Temperature | 134°C |
| Working Pressure | 0.22 Mpa |
| Timer Range | 0-99 min |
| Rapid Sterilization | 4 – 6 minutes |
| Sterilizing Plates | 4 |
| Heat Average | ≤ ±1°C |
| Sterilizing Chamber Dimension | ɸ300×500 mm |
| Sterilizing Plate Dimension | 400×200×30 mm |
| Dimension (L×W×H) | 730×550×510 mm |
| Exterior Package Dimension (L×W×H) | 810×680×650 mm |
| Gross Weight | 90 Kg |
| Net Weight | 73 Kg |
High grade stainless steel chamber
Rapid action door closure mechanism
Standard operation via a digital display
High-efficiency and easy to use
Exhausts the cool air automatically
Water adding, sterilizing, dry steam discharging are controlled automatically
Steam-water inner circulation system
Electrical draining of water reservoir
Automatic purging of steam and exhaust with water
Fully automatic micro-computer controlled operation
Leak-proof sealing with gasket design
Offers rapid sterilization of 4 – 6 minutes within 105°C to 134°C temperature range
Provides clean and dry environment for sterilization
Safety door lock system
It is an ideal equipment for sterilization in healthcare, Pharmacy QC, QA, R&D, chemical plants, dental clinics, biotechnology labs, water & air pollution labs and mineral water plants etc.
