EziLab offers the Shaker Incubator EZL-SI84, a large capacity incubator shaker with a 582 L chamber for bioprocess development and culture work beyond standard microbiology volumes. Choose it over the 170 L and 280 L models when parallel cultures, seed trains, or fermentation studies need dozens of flasks under identical conditions. Two 970 × 760 mm trays hold 45 × 250 mL or 37 × 500 mL flasks as standard, and alternative configurations reach 90 × 25 mL, 36 × 1000 mL, or 8 × 5000 mL. A high-torque motor drives a φ26 mm orbit from 40 to 300 rpm at ±1 rpm for long runs. Temperature runs from RT +5°C to 60°C with ±0.1°C accuracy and ±1°C uniformity, and audible and visual alarms trigger if the chamber drifts more than 3°C from setpoint. Non-volatile memory restarts the program after a power loss, protecting multi-day cultures. Flask clamps and platforms are included, and a lighted window allows checks without opening the door. Bioprocess teams run scale-up studies, microbiology labs grow bacterial and yeast cultures, biochemistry groups run hybridization work, and cell biology labs incubate tissue cultures and plates. See the Shaker Incubator and Shaker Incubator EZL-SI84 pages for full specifications.
| Volume | 582 L |
|---|---|
| Shaking Speed | 40 to 300 rpm |
| Speed Accuracy | ± 1 rpm |
| Swing Amplitude | φ 26 mm |
| Temperature Range | RT +5°C-60°C |
| Standard Configuration | 250ml×45 or 500ml×37 |
| Maximum Capacity | 25ml×90/500ml×74/1000ml×36/5000ml×8 |
| Tray Size | 970×760 mm |
| Tray Included | 2 |
| Temperature Accuracy | ± 0.1°C |
| Temperature Uniformity | ± 1°C |
| Timing Range | 1-9999 Minutes |
| Power Rating | 1420 W |
| Volume (W×D×H) | 109.5×62.5×85 mm |
| Exterior Dimension (W×D×H) | 120×82×160 mm |
| Net Weight | 456 kg |
It is a combination of an incubator and a shaker
Flask clamps, plastic clamps, funnel clumps and dedicated platforms are provided
The shell is made of high-quality steel, and the chamber is polished stainless steel
Panel with a sloped design and a large LCD display
A data memory function is available to eliminate faulty operation
Non-volatile memory that, when power is restored, the unit will automatically restart as originally programmed
The heating is switched off and audible and visual alarm are alerted if the measuring temperature deviates from the set temperature by 3°C
Complex and quick refrigeration system for faster cooling and automatic defrost
A high-torque motor for continuous operation
A large view window and built-in lighting for easy observation
Low noise, luxury and leak resistant
These double layer shaking incubators have been designed specifically for modern biological engineering departments, and include bacterial, tissue, germ cultures, yeast and liquid culture incubation, culture plates, fermentation, hybridization and biochemical research. All of these tests require high temperature performance as well as a stable vibration frequency.
