EziLab offers the Coulometric Karl Fischer Titrator EZL-CKT100, a KF titrator that measures water content from 0 to 100 mg at 0.1 µg resolution. Coulometric titration generates iodine electrochemically inside the cell at up to 40 µg/s, with electrolyzed water held within 2 µg between 10 and 1000 µg and within 0.2% above 1000 µg. A dot-matrix LCD with screen protection, a calendar clock, and storage for 255 timestamped results come standard. The five-opening electrolytic cell, paired measuring and electrolysis electrodes, stirrers, and sample filling devices up to 1 ml let analysts inject liquids for Karl Fischer titration. Its low range suits samples with little water, such as anhydrous solvents, pharmaceutical powders, and raw materials, where a small moisture shift changes stability or shelf life. As a Karl Fischer moisture analyzer, it also prints results for batch records. Petroleum refineries and power utilities check fuels and transformer oils for trace water, while chemical and pesticide producers test solvents and intermediates before release. Pharmaceutical QC labs, railway maintenance labs, and environmental protection agencies round out the user base. At just 5 kg, it fits crowded shared benches. See the Water Content Testers and Coulometric Karl Fischer Titrator pages for full specifications.
| Measurement Range | 0 to 100 mg |
|---|---|
| Resolution | 0.1 µg |
| Amount and Precision of Electrolyzed Water |
1) 10 µg to 1000 µg，±2 µg 2) >1000 µg，0.2% |
| Maximum Electrolysis Speed | 40 µg/s |
| Ambient Temperature | 10℃ to 35℃ |
| Relative Humidity | ≤85% |
| Power Consumption | 30 W |
| Dimension | 320×240×150 mm |
| Weight | 5 Kg |
Graphics dot-matrix LCD screen
Stores up to 255 data points with timestamps
Incorporated with a calendar clock
Equipped with screen protection
Electrolytic Cell Bottle (Measuring bottle with 5 openings) × 1 Measuring Electrode × 1 Electrolysis Electrode × 1 Electrolytic Cell Inlet Sample Stopper × 1 Large Glass Ground Stopper × 1 Small Glass Ground Stopper (with notch) × 1 Small Glass Ground Stopper × 1 Stirrer × 2 Sample Filling Device 0.5 pl × 1 Sample Filling Device 50 pl × 1 Sample Filling Device 1 ml × 2 Straight Drying Tube × 1 Power Line × 1 Vacuum Grease × 1 Electrolyte × 1 Printer Paper × 1 Silica Gel Bead × 1 Silicone Pad × 10
Coulometric Karl Fischer Titrator is extensively applicable across industries such as petroleum, chemical, power, railway, pesticide, medicine, and environmental protection for detecting water content in various substances.
