EziLab Automatic Solidifying Point and Pour Point Tester EZL-SPPT100 measures solidifying and pour points for light oils across oil refineries, fuel stations, transformer oil checks, gasoline evaluation, and light diesel testing applications. Test range covers -60C to 10C with 0.1C display resolution, while cooling performance enables large temperature differentials for rapid cloud point analyzer test execution. Sample volume of 20 mL per run supports standardized testing, and water pressure and flow requirements maintain stable cooling performance during operation. The system aligns with common petroleum test standards for routine laboratory use without complex setup. EziLab's Lab Equipment and petroleum testing equipments list the full pour point tester and solidifying point analysis range.
| Solidifying Point | -60℃ to 10℃ |
|---|---|
| Precision | ±1℃ |
| Ambient Temperature | 25±10℃, RH < 85% |
| Display Resolution | 0.1℃ |
| Maximum Cooling Depth | Temperature difference ≥ 65℃ |
| Cooling Speed | 15min temperature difference ≥ 60℃ |
| Requirement For Cooling Water Pressure | 4.9 × 10 to 49 × 105Pa |
| Flow Rate | 1.5L/min |
| Sample Dose | 20ml per time |
| Standards | GB/T 510, ASTM D852, GB/T3535, ASTM D97 |
| Maximum Power Consumption | 250W |
| Power Supply | AC220V±22V，50Hz |
| Dimension | 460mm × 360 mm × 470mm |
| Net Weight | 26Kg |
Highly automated with advanced design
A micro-printer is installed
The test accuracy is excellent and rapid
It uses SCM as the primary control system
This requires a minimal sample for testing
A colored touch screen
Printer Paper × 2 Fuse (Φ5 × 20,10A) × 2 Power Line (250V / 6A) × 1 Circulatory Water Pipe and Drain Line × 5
Low temperature circulatory water bath
It has a wide range of applications in oil refineries, oil stations, and other related institutions. It's used to find the solidifying and pour points of light oils with good flow and low viscosity, like gasoline, light diesel, and transformer oil.
