EziLab Low Temperature Kinematic Viscometer EZL-KV200 measures viscosity of petroleum products under controlled sub-zero bath conditions across low-temperature liquid petroleum, transformer oil, aviation fuel, and cold-flow evaluation applications. Temperature range covers -65C to room temperature with stable control accuracy, while dual refrigeration compressors provide consistent cooling performance for extended kinematic viscosity meter test cycles. A stainless-steel constant temperature bath maintains uniform thermal conditions, and Pt100 sensing monitors temperature stability for repeatable viscosity calculations. Pinkevitch capillary tubes enable controlled flow measurements across viscosity ranges. EziLab's Lab Equipment and petroleum testing equipments stock the full low temperature viscosity meter and sub-zero petroleum testing range.
| Temperature Range | ‘-65℃ to RT |
|---|---|
| Temperature Control Accuracy | ±0.1 ℃ |
| Ambient Temperature | 15℃ to 35℃ |
| Temperature Sensor | RTD, Pt100 |
| Relative Humidity | ≤ 85% |
| Heating Device | Electric heater |
| Heating Device Power | ≤ 600 W |
| Refrigeration Unit | Double refrigeration compressors |
| Constant Temperature Bath | Stainless steel |
| Capillary Viscometer Tubes (Pinkevitch Viscometer) | 6 pieces |
| The Diameters for Each Piece | 0.6, 0.8, 1.0, 1.2, 1.5, 2.0 mm |
| Power Supply | AC (220 ± 10%) V 50Hz |
| Maximum Power Consumption | 1700 W |
| Dimensions | 530mm × 460mm × 870mm |
It can accommodate dual samples
Uniform temperature ensured by stirring motor
Bath LEDs improve viscometer clarity for convenient readings
Dual compressors optimize cooling in the unit
Constant temperature bath is made of stainless steel
Main Unit × 1 Capillary Viscometer (Total 6 Pieces) × 1 Thermometer (-80 to 20℃, Each Graduation 0.5℃) × 1 Bath Cover × 1 Capillary Clamps × 2 Plastic Pump × 1 Stopping Ring for Thermometer (1#) × 2 Ear Washing Bulb × 1
Our Low Temperature Kinematic Viscometer is appropriate for measuring the kinematic viscosity of liquid petroleum products, specifically Newtonian liquids, under consistent low temperatures.
